Артикул: DHI-VTH5341G-W
Cрок поставки : 30 марта

Dahua DHI-VTH5341G-W монитор видеодомофона и для систем видеонаблюдения 10" с DVR

DHI-VTH5341G-W Монитор видеодомофона IP 10-и дюймовый

WiFi 2.4ГГц,

черный 1024x600 разрешение,

ёмкостной сенсорный экран;

тревожные входы / выходы 8/1;

LAN;

поддержка micro-SD до 265Гб;

Возможность просмотра IP видеокамер;

Питание:  DC 12В/PoE;

Габаритные размеры: 260 мм × 170 мм × 15 мм;

Установка - на стену.


Производство Dahua. Китай.

DHI-VTH5341G-W Монитор видеодомофона IP 10-и дюймовый

WiFi 2.4ГГц,

черный 1024x600 разрешение,

ёмкостной сенсорный экран;

тревожные входы / выходы 8/1;

LAN;

поддержка micro-SD до 265Гб;

Возможность просмотра IP видеокамер;

Питание:  DC 12В/PoE;

Габаритные размеры: 260 мм × 170 мм × 15 мм;

Установка - на стену.


Производство Dahua. Китай.

  • Описание


    System

    Main Processor

    Embedded processor

    Operating System

    Android 8.1

    Network Protocol

    IPv4, TCP, SIP, UDP, RTSP

    Basic

    Screen Type

    Capacitive screen

    Display Screen

    10 inch TFT LCD

    Resolution

    1024×600

    Video Compression

    H.264

    Audio Compression

    PCM

    Audio Input

    1 omnidirectional microphone

    Audio Output

    Built-in 1.5W speaker

    Audio Mode

    Two-way voice call

    Audio Enhancement

    Echo suppression/DNR

    Audio Bit Rate

    16KHz, 16Bit

    Function

    Information Release

    Text announcements released by the management center can be viewed

    Communication Mode

    Full digital

    Elevator Control

    You can control the elevator through the indoor monitor

    Leave Videos or Text Messages

    Yes (SD card is needed)

    DND Mode

    Do not disturb period can be set.

    Extension Number

    Villa: 4

    Apartment: 9

    Wi-Fi

    Yes

    Wireless Standard

    IEEE802.11b/802.11g/802.11n

    Wireless Frequency Range

    2.4GHz

    Wireless Security-Encryption

    64/128bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

    Storage

    Micro SD storage, the maximum space is 256GB

    Port

    RS-485

    1

    Alarm Input

    8

    Alarm Output

    1

    Power Output

    1 12V/100mA

    Door Bell

    Yes, use alarm input port

    Network Port

    1 10M/100M Ethernet

    Alarm

    SOS

    Yes

    Performance

    Housing Material

    PC+ABS

    Regular

    Color

    Black

    Power Supply

    12V DC 1A
    Standard POE

    Installation

    Surface mount

    Certifications

    CE
    FCC

    Accessory

    Surface mount bracket, alarm ribbon cable, RS-485 cable, and power-supply pins are provided

    Product Dimensions

    260 mm×170 mm×15 mm (10.24"×6.69"×0.59") (ports are not counted) 260 mm×170 mm×25.4 mm (convex) (10.24"×6.69"×1") (ports are counted)

    Operating Temperature

    -10°C to +55°C (+14°F to +131°F)

    Operating Humidity

    10%RH–95%RH (Non-condensing)

    Operating Altitude

    Less than 3,000 meters (9842.52 ft)

    Power Consumption

    ≤1.5W (standby), ≤7W (working)

    Net Weight

    770g (1.70lb)

    Gross Weight

    1.1kg (2.43lb)

    Dahua DHI-VTH5341G-W монитор видеодомофона имеет встроенную ОС Андроид, что позволяет устанавливать сторонние приложения.

  • Документы

    Информация DHI-VTH5341G-W_datasheet_20200113.pdf
    643.8 кб, 17 августа в 14:07
    IP Indoor Monitor_User's Manual_V1.0.0-Eng.pdf
    1.9 Мб, 17 августа в 14:06
    IP Indoor Monitor_Quick Start Guide_V1.0.0-Eng.pdf
    1.1 Мб, 17 августа в 14:06
    IP Indoor Monitor_Installation Guide_V1.0.0-Eng.pdf
    627.6 кб, 17 августа в 14:05
